Textile businesses have a unique storage dilemma that most rack manufacturers completely ignore.

Fabric rolls cannot be stacked flat – they deform and crease under pressure. Finished garments cannot be stored in tight spaces – they wrinkle and lose their presentation. Yarn cones and bobbins tip over if not held upright. Sarees, dress materials, and heavy fabric bolts can weigh 5–15 kg each – multiply that by hundreds of rolls and you need racks that are not just strong but designed for the shape and nature of textile goods.

Advance Engineering has built custom textile storage racks for weaving mills, fabric manufacturers, garment exporters, saree showrooms, and textile warehouses across Gujarat – India’s largest textile state.

We understand that in the textile industry, damaged fabric is unsellable fabric. Creased garments mean returns. Poor storage leads to color fading, moisture damage, and lost inventory.

Our racks protect your product while making your warehouse dramatically more organized and efficient.

The Real Storage Problems in a Textile Warehouse – And Why Normal Racks Don’t Work

Problem – Fabric Rolls Need Horizontal Arm Support, Not Flat Shelves

A fabric roll stored on a flat shelf compresses on the bottom edge over time. This creates a deformed, flat-sided roll that is difficult to unroll on a loom or cutting table. Worse, if heavy rolls are stacked on top of lighter ones, the bottom rolls can be damaged irreparably.



The Right Solution: Cantilever racks with horizontal arms that support fabric rolls from below, like a rod running through the core of the roll. This keeps the roll perfectly round, prevents edge deformation, and allows any roll to be removed without disturbing the others.

Problem – Garments Lose Shape in Tightly Packed Storage

Finished garments – suits, sarees, dress materials – lose shape, develop permanent fold marks, and lose their showroom freshness when compressed into tight spaces or stacked too high.



The Right Solution: Long-span shelving racks with wide bays and generous vertical clearance between shelves. Garments can be kept folded or on hangers (with rod attachments available on our racks), with enough air circulation to prevent moisture buildup.

Problem – Yarn Cones and Bobbins Tip, Fall, and Get Mixed Up

Yarn storage is a nightmare in poorly organized facilities. Cones tip over, bobbins roll away, and different yarn counts get mixed in the same bin – causing costly production errors when the wrong yarn enters the weaving machine.



The Right Solution: Slotted angle racks with custom bin dividers that create individual compartments for each yarn type. Upright dividers prevent tipping. Labels on every bin ensure the right yarn reaches the right machine every time.

Problem – Finished Goods Take Forever to Find

A textile warehouse with 200+ fabric designs, colors, and variants becomes a maze when there is no structured storage system. Workers spend 20–40 minutes per order just locating the right roll.



The Right Solution: A rack system with a location coding system – Row A, Bay 01, Level 02 – combined with a physical rack label at every position. When racks are numbered and goods are mapped to a location, finding any product takes under 2 minutes.

Problem – Small Showrooms Don’t Have Space for Large Racks

Not every textile business has a massive warehouse. Saree showrooms, fabric retail stores, and boutique garment manufacturers often operate in 500–1,500 sq. ft. with low ceilings and high SKU counts.



The Right Solution: Compact slotted angle racks customized to room dimensions, with vertical space utilization up to 2.5 m and modular bays that can be added as the business grows.

Types of Storage Racks We Build for the Textile Industry

Fabric Roll Storage Racks (Horizontal Cantilever Style)

This is our most requested product from weaving mills and fabric manufacturers. The cantilever arms hold fabric rolls horizontally, perpendicular to the central column. Key features:

  • Arms adjustable in height to accommodate different roll diameters
  • Single-sided or double-sided cantilever configuration
  • Arm capacity of 100–500 kg per arm depending on roll weight
  • Length of arms from 600 mm to 1,500 mm
  • Powder-coated in standard orange/grey or custom colors
  • No front-column obstructions – full-width access to every roll position

Garment Storage Racks with Hanging Rod Attachment

For finished garments that need to be hung rather than folded, we manufacture long-span shelving frames with crossbar rod attachment points. This creates a garment warehouse style of storage within a structured rack system. Features:

  • Rod spacing of 400–600 mm (vertical) to allow full garment hang without bunching
  • Shelf decking below rods for accessory storage (tags, packaging, hangers)
  • Available in widths from 1,200 mm to 2,700 mm
  • Mobile rack version available for garment export houses requiring frequent reorganization

Yarn and Cone Storage Shelving

Our slotted angle and long-span shelving racks are configured specifically for yarn cone storage with these adaptations:

  • Custom-height bin dividers (150–300 mm) inserted into rack slots
  • Color-coded bin labels for yarn count and shade identification
  • Shelf depth of 400–600 mm for two rows of cones front-to-back
  • Anti-static powder coating option for sensitive synthetic yarn storage

Multi-Tier Racks for Textile Warehouses

Textile businesses often grow faster than their warehouse floor allows. Our multi-tier racking system is the most effective way to double your storage capacity without moving to a bigger facility. We have designed 2-tier and 3-tier textile rack systems with:

  • Steel mezzanine floor at upper level (grating or sheet metal decking)
  • Staircase access with safety railings per factory safety standards
  • Load capacity of 400–800 kg per square metre on upper levels
  • Fast-moving goods on lower level, slow-moving goods on upper level

Textile Industries We Serve

Segment Common Rack Type
Weaving mills Cantilever fabric roll racks
Saree manufacturers Long span shelving + hanging racks
Garment export houses Multi-tier + hanging garment racks
Yarn spinning mills Slotted angle + bin divider shelving
Fabric retail showrooms Compact slotted angle display racks
Textile warehouses & CFA agents Heavy duty pallet racks
Embroidery and lace manufacturers Slotted angle shelving + clear bins

Why Textile Companies in Gujarat Choose Advance Engineering

Gujarat is home to India’s largest concentration of textile manufacturers – from Surat’s fabric industry to Ahmedabad’s garment and mill businesses. We understand the pressure of this market: fast production cycles, export commitments, and storage spaces that are always bursting at capacity.

Here is what our textile clients consistently tell us:

“Before the rack system, we were wasting 40 minutes per order locating rolls. Now it takes under 5 minutes.”

“The cantilever roll racks have completely eliminated the deformation problem we were having with bottom rolls.”

“The multi-tier system gave us double the storage in the same building. We avoided renting a second warehouse.”

Our manufacturing facility at Moraiya, Sanand is just 30 minutes from central Ahmedabad – allowing us to serve local textile clients with fast turnaround and on-site visits before and during installation.

Frequently Asked Questions – Textile Industry Storage Racks

What type of rack is best for storing fabric rolls without damaging them?

Cantilever racks with horizontal arms are the best option for fabric roll storage. The roll sits on two horizontal arms (or a single rod through the core) with nothing compressing the roll from the sides or below. This maintains the roll’s shape perfectly for months without any deformation or edge damage. This is the industry-standard solution used in weaving mills and fabric warehouses globally.

Can you make racks for a saree showroom that looks good visually, not just functional?

Absolutely. For retail-facing showrooms, we offer powder-coated racks in premium colors (white, cream, champagne, custom brand colors) with clean, furniture-quality welds and optional decorative end panels. These racks look professional in a customer-facing environment while providing all the structural strength of an industrial rack.

How do I prevent moisture and color fading in fabric storage?

The rack itself is the first step – keeping fabric off the floor (where moisture accumulates) and away from walls (where condensation forms) is critical. Our racks have a minimum 150 mm floor clearance. Additionally, the ventilated open shelf design of our long-span shelving allows air circulation around stored fabric, reducing humidity buildup compared to closed cabinets.

Can your racks store heavy fabric rolls (20–50 kg per roll)?

Yes. Our cantilever arms are individually rated from 100 kg to 500 kg per arm. For very heavy rolls (50+ kg), we engineer custom arm profiles and column sizes rated to the specific load. We always ask for roll weight information before finalizing the design for fabric roll storage racks.

What is the typical timeline for a textile warehouse rack project in Ahmedabad?

For a standard textile warehouse of 3,000–8,000 sq. ft., the timeline is typically 10–18 working days from site visit to final installation. This includes design, manufacturing, and on-site erection. Showroom rack projects for smaller spaces are typically completed in 5–8 days.

Do you supply racks to textile businesses outside Ahmedabad?

Yes. We regularly supply and install racks for textile businesses in Surat, Rajkot, Bhavnagar, Anand, Nadiad, and across Gujarat. We also serve textile clients in Mumbai, Delhi, and other major cities. Contact us with your location for a delivery and installation timeline.
